LCS-4 L-Band Combiner Switch Revision 1
Low Noise Block Assembly MN/LCS4.IOM
4.3.3 A
SSEMBLE
R
EDUNDANT
C-B
AND
LNB
Part No. Nomenclature QTY
28P1084 Adapter 1
CN/CX50NMALE Termination, 50 Ω 1
GA/GSKTCPOR229FULL Gasket, CPR229 4
HW/1/4-20X5/8BT Bolt, 1/4-20 30
HW/1/4-FLT Washer, Flat 30
HW/1/4-SPLIT Washer, Split 30
SW/WGS+48V-229 Switch, Waveguide WR229, +48 VDC 1
*Customer-Furnished LNB 2
Note: Not included in Kit. May be customer-furnished or ordered separately from CEFD.
Figure 4-1. C-Band Redundant LNB (KT/9526-1)
4–3
