LCS-4 L-Band Combiner Switch Revision 1
Remote Control Operation MN/LCS4.IOM
A-8
Parameter
Type
Command
(Instruction
Code and
qualifier) Arguments
for Cmd or
Response
to Query
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Response to
Command
(Target to
Controller) Query
(Instruction
code and
qualifier)
Response to query
(Target to Controller)
BUC A
Current
Window BCA= 2 bytes,
numerical
Command or Query.
BUC A Current Monitor Window, this command allows
the user to set the alarm window in
±% of the
calibrated BUC A Current. Valid inputs are 20 to 50 in
increments of 1%. In addition, setting the value to 99
disables the alarm function.
Example: BCA=30, set the alarm window at
±30%
Parameter 6 of the SGC Command.
BCA= (message ok)
BCA? (received ok,
but invalid
arguments found) BCA? BSA=xx
(same format as command
arguments)
BUC B
Current
Window BCB= 2 bytes,
numerical
Command or Query.
BUC B Current Monitor Window, this command allows
the user to set the alarm window in
±% of the
calibrated BUC B Current. Valid inputs are 20 to 50 in
increments of 1%. In addition, setting the value to 99
disables the alarm function.
Example: BCB=30, set the alarm window at
±30%
Parameter 7 of the SGC Command.
BCB= (message ok)
BCB? (received ok,
but invalid
arguments found) BCB? BSB=xx
(same format as command
arguments)
LNB Power
Supply A
Enable LSA= 1 byte,
value of 0,1 Command or Query.
LNB A Power Supply, where:
0=Disabled
1=Enabled
Example: LSA=1
Parameter 10 of SGC Command LSA= (message ok)
LSA? (received ok,
but invalid
arguments found)
LSA*(message ok,
but not permitted in
current mode) LSA? LSA=x (same format as command
arguments)
LNB Power
Supply B
Enable LSB= 1 byte,
value of 0,1 Command or Query.
LNB B Power Supply, where:
0=Disabled
1=Enabled
Example: LSB=1
Parameter 11 of SGC Command LSB= (message ok)
LSB? (received ok,
but invalid
arguments found)
LSB*(message ok,
but not permitted in
current mode) LSB? LSB=x (same format as command
arguments)
LNB A
Reference
Oscillator
Enable LRA= 1 byte,
value of 0,1 Command or Query.
LNB A reference Oscillator, where:
0=Disabled
1=Enabled
Example: LRA=1
Parameter 12 of SGC Command LRA= (message ok)
LRA? (received ok,
but invalid
arguments found)
LRA*(message ok,
but not permitted in
current mode) LRA? LRA=x (same format as command
arguments)
