LCS-4 L-Band Combiner Switch Revision 1
Low Noise Block Assembly MN/LCS4.IOM
4.5 S
ETTINGS
(LNB) L
O
, M
IX AND
S
PECTRUM
4.5.1 C-B
AND
Table 4-1. For C-Band: LO and MIX Information for Demodulator and LNB
LNB Part No. Description
LO
(Offset)
Frequency
(MHz)
MIX
(+/-)
Min
LNB
Satellite
Frequency
(MHz) Max
LNB
Satellite
frequency
(MHz) L-Band
Frequency
at LNB
Min
(MHz) L-Band
Frequency
at LNB
Max
(MHz) Demod
Spectrum
(Utility
Demod
Menu)
Operating
Voltage,
V
RF
Connector
RF/LNB-C-55-35N 3.625 – 4.200 GHz
EXT REF 5,150.00 _ 3.625.00 4,200.00 1,525.00 950.00 Invert 18 Type N
RF/LNB3.6-4.2FE 3.625 – 4.200 GHz
EXT REF 5,150.00 _ 3.625.00 4,200.00 1,525.00 950.00 Invert 18 Type N
RF/LNB3.6-4.2F03 3.625 – 4.200 GHz
EXT REF 5,150.00 _ 3.625.00 4,200.00 1,525.00 950.00 Invert 18 Type N
xxxxxxxxxxxxxx 3.625 – 4.200 GHz 5,150.00 _ 3.400.00 4,200.00 1,525.00 950.00 Invert 18 Type N
xxxxxxxxxxxxx 4.500 – 4.800 GHz 5,150.00 _ 4,500.00 4,500.00 1,525.00 950.00 Invert 18 Type N
4.5.2 K
U
-B
AND
Table 4-2. For Ku-Band: LO and MIX Information for Demodulator and LNB
LNB Part No. Description
LO
(Offset)
Frequency
(MHz)
MIX
(+/-)
Min
LNB
Satellite
Frequency
(MHz) Max
LNB
Satellite
frequency
(MHz) L-Band
Frequency
at LNB
Min
(MHz) L-Band
Frequency
at LNB
Max
(MHz) Demod
Spectrum
(Utility
Demod
Menu)
Operating
Voltage,
V
RF
Connector
RF/LNB-10.9-
11.7FE 10.95-11.7 GHz
EXT REF 10,000.00 + 10,950.00 11,700.00 950.00 1700.00 Normal 18 Type F
RF/LNB-11.7-
12.2FE 11.7 – 12.2 GHz
EXT REF 10,750.00 + 11,700.00 12,200.00 950.00 1450.00 Normal 18 Type F
RF/LNB-12.2-
12.7FE 12.25 – 12.75 GHz
EXT REF 11,300.00 + 12,250.00 12,750.00 950.00 1450.00 Normal 18 Type F
RF/LNB10.9-
11.7F03 10.95 – 11.7 GHz
± 3 ppm 10,000.00 + 11,200.00 11,700.00 950.00 1450.00 Normal 18 Type F
RF/LNB-11.7-
12.2F03 11.7 – 12.2 GHz
± 3 ppm 10,750.00 + 10,950.00 11,700.00 950.00 1700.00 Normal 18 Type F
RF/LNB-12.2-
12.7F03 12.25 – 12.75 GHz
± 3 ppm 11,300.00 + 12,250.00 12,750.00 950.00 1450.00 Normal 18 Type F
4–11
