LCS-4 L-Band Combiner Switch Revision 1
Block Up Converter MN/LCS4.IOM
5.4.2 K
U
-B
AND
Table 5-2. LO, MIX, and MOD Spectrum Settings for Modulator and BUC
P1dB_min
Band
FSK
CEFD
Part #
RF Start
Frequency
(GHz)
RF End
Frequency
(GHz) LO
(Offset)
Freq.
(MHz)
MIX
(+ / -) Modem
Spectrum
(Utility
Modulator
Menu)
Supply
Voltage
SPAR
Mount Kit
Feed Mount Kit
*2 Watt Ku Yes RF/BUC02KU-A-F-T 14.00 14.50 13,050.00 + Normal 24 VDC KT/8924-1 KT/9928-1
*4 Watt Ku Yes RF/BUC04KU-A-F-T 14.00 14.50 13,050.00 + Normal 24 VDC KT/8924-1 KT/9928-1
*8 Watt Ku Yes RF/BUC08KU-A-N-N 14.00 14.50 13,050.00 + Normal 48 VDC KT/8924-1 KT/9928-1
**1 Watt Ku No RF/BUC01KU-A-N-N 14.00 14.50 15,450.00 - Invert 24 VDC KT/8924-1 KT/9928-1
**2 Watt Ku No RF/BUC02KU-A-N-N 14.00 14.50 15,450.00 - Invert 24 VDC KT/8924-1 KT/9928-1
**4 Watt Ku No RF/BUC04KU-A-N-N 14.00 14.50 15,450.00 - Invert 24 VDC KT/8924-1 KT/9928-1
*2 Watt Ku EXT Yes RF/BUC02KU-B-F-T 13.75 14.25 12,800.00 + Normal 24 VDC KT/8924-1 KT/9928-1
*4 Watt Ku EXT Yes RF/BUC04KU-B-F-T 13.75 14.25 12,800.00 + Normal 24 VDC KT/8924-1 KT/9928-1
*8 Watt Ku EXT Yes RF/BUC08KU-B-F-T 13.75 14.25 12,800.00 + Normal 48 VDC KT/8924-1 KT/9928-1
**1 Watt
(Typical)
28 dBm Ku EXT No RF/BUC01KU-B-N-N 13.75 14.25 15,200.00 - Invert 24 VDC KT/8924-1 KT/9928-1
**2 Watt Ku EXT No RF/BUC02KU-B-N-N 13.75 14.25 15,200.00 - Invert 24 VDC KT/8924-1 KT/9928-1
* Option A BUC Mounting
** Option B BUC Mounting
5–8
