LCS-4 L-Band Combiner Switch Revision 1
Remote Control Operation MN/LCS4.IOM
A-9
Parameter
Type
Command
(Instruction
Code and
qualifier) Arguments
for Cmd or
Response
to Query
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Response to
Command
(Target to
Controller) Query
(Instruction
code and
qualifier)
Response to query
(Target to Controller)
LNB B
Reference
Oscillator
Enable LRB= 1 byte,
value of 0,1 Command or Query.
LNB B reference Oscillator, where:
0=Disabled
1=Enabled
Example: LRB=1
Parameter 13 of SGC Command LRB= (message ok)
LRB? (received ok,
but invalid
arguments found)
LRB*(message ok,
but not permitted in
current mode) LRB? LRB=x (same format as command
arguments)
LNB Fault
Logic LFL= 1 byte,
value of 0,1 Command or Query.
LFL controls whether or not the Summary Fault Relay
(SFR) is affected by the BUC Volt or Current window
monitor, where:
0=A LNB Volt/Current Fault does not effect the SFR,
1=A LNB Volt/Current Fault will effect the SFR.
Example: LFL=1
Parameter 16 of SGC Command LFL= (message ok)
LFL? (received ok,
but invalid
arguments found) LFL?
LFL=x (same format as command
arguments)
LNB A
Current
Window LCA= 2 bytes,
numerical
Command or Query.
LNB A Current Monitor Window, this command allows
the user to set the alarm window in
±% of the
calibrated LNB A Current. Valid inputs are 20 to 50 in
increments of 1%. In addition, setting the value to 99
disables the alarm function.
Example: LCA=30, set the alarm window at
±30%
Parameter 14 of the SGC Command.
LCA= (message ok)
LCA? (received ok,
but invalid
arguments found) LCA? LCA=xx
(same format as command
arguments)
LNB B
Curent
Window LCB= 2 bytes,
numerical
Command or Query.
LNB B Current Monitor Window, this command allows
the user to set the alarm window in
±% of the
calibrated LNB B Current. Valid inputs are 20 to 50 in
increments of 1%. In addition, setting the value to 99
disables the alarm function.
Example: LCB=30, set the alarm window at
±30%
Parameter 15 of the SGC Command.
LCB= (message ok)
LCB? (received ok,
but invalid
arguments found) LCB? LCB=xx
(same format as command
arguments)
Calibrate All
Limits CAL= 2 bytes,
numerical
Command only.
This command is used to set the calibration point for
the BUC/LNB Current alarm feature.
Example: CAL= CAL=(message ok) N/A N/A
Calibrate
BUC A Limits CBA= None/5
bytes
numerical Command or Query.
This command is used to set the calibration point for
the BUC A Current alarm feature.
Command Example: CBA=
Query Example: CBA=02120 CBA=(message ok) CBA? CBA=xxxxx
(same format as command
arguments)
