LCS-4 L-Band Combiner Switch Revision 1
Block Up Converter MN/LCS4.IOM
5.2.1 A
SSEMBLE
W
AVEGUIDE
S
WITCH
K
IT
, AS/9528-1
Part No. Nomenclature QTY
FP/WG0034 Termination, Small Fins 1
FP/WG0043 Waveguide, CPRG137 1
FP/WG0051 Waveguide, CPRG137 1
GA/GSKTCP137FULL Gasket, CP137 Full 4
HW/10-32X5/8SHC Screw, Socket Head Cap 32
HW/10-FLT Washer, Flt 32
HW/10-SPLIT Washer, Spit 32
SW-WGS+48V-137SB Switch, Waveguide (CPR130) 1
*Customer-Furnished LNB 2
1. Place gasket (GA/GSKTCP137FUL) on waveguide Port 1 of Switch
(SW-WSC+48V-137SB).
2. Assemble one waveguide (FP/WG10359-1) and secure with six screws, flat washers,
and split washers to Port 1 of Switch.
3. Place gasket on waveguide Port 3 of switch.
4. Assemble second waveguide to Port 3 of Switch and secure using six screws, flat
washers, and split washers.
5. Install termination (FPWG00354) and gasket to Port 4 of switch and secure using six
screws, flat washers, and split washers.
IMPORTANT
Port 2 of the Switch is reserved for customer-furnished equipment.
Cover Port 2 until used.
5–2
