Comtech EF Data LCS-4 - Manual (Page 80)

LCS-4 L-Band Combiner Switch Revision 1
Remote Control Operation MN/LCS4.IOM
A-16
Parameter
Type
Command
(Instruction
Code and
qualifier) Arguments
for Cmd or
Response
to Query
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Response to
Command
(Target to
Controller) Query
(Instruction
code and
qualifier)
Response to query
(Target to Controller)
Retrieve
Maintenance
Status N/A 159 bytes,
alpha
numerical
Query only.
Used to Query the maintenance status of the LCS-4
Example: RMS=’cr’
48VPS=048.0’cr’
12VP1=012.0’cr’
12VP2=012.0’cr’
P5.0V=+05.0’cr’
N5.0V=-05.0’cr’
BUCAV=024.0’cr’
BUCBV=024.0’cr’
BUCAC=02500’cr’
BUCBC=02500’cr’
LNBAV=018.0’cr’
LNBBV=018.0’cr’
LNBAC=125.0’cr’
LNBBC=125.0’cr’
REFVT=005.0’cr’
FAN C=725.0’cr’
TEMPO=025.0’cr’’lf’]
N/A RMS? RMS=x…x
(same format as command
arguments)
Concise
Maintenance
Status N/A 80 bytes,
numerical Query only.
Used to Query the Maintenance status of the LCS-4
Example: CMS=aaa.a,bbb.b,ccc.c,ddd.d,eee.e
fff.f,ggg.g,hhh.h,iii.i,jjj.j,kkk.k,lll.l,mmm.m
nnn.n,ooo.o,ppp.p’cr’’lf’
where:
aaa.a = Main 48V Power Supply
bbb.b = 12V Power Supply 1
ccc.c = 12V Power Supply 2
ddd.d = +5V Power Supply
eee.e = -5V Power Supply
fff.f = BUC A Power Supply
ggg.g = BUC B Power Supply
hhh.h = BUC A Current in milliampers
iii.i = BUC B Current in milliamperes
jjj.j = LNB A Power Supply
kkk.k = LNB B Power Supply
lll.l = LNB A Current in milliampers
mmm.m = LNB B Current in milliampers
nnn.n = Reference Tune Voltage
ooo.o = Fan Current in milliampers
ppp.p = Unit Temperature
N/A CMS? CMS=x….x (see description for
details of arguments)
