5.5 S
INGLE
-T
HREAD
BUC I
NSTALLATION
CAUTION
After removing the protective covers, ensure that no foreign material (FOD)
or moisture enters.
5.5.1 T
OOLS
R
EQUIRED
1/2-inch Box Wrench (or equivalent)
5/16-inch Box Wrench (or equivalent)
7/16-inch Box Wrench (or equivalent)
7/64-inch SAE Allen
M3 Metric Allen Wrench
Screw Driver Phillips
5.5.2 M
OUNTING
K
ITS
Table 5-3. Optional: C-Band Mounting Kit, KT/5738-1 (BUC to OMT)
Table 5-4. Optional: Ku-Band Mounting Kit, KT/8924-1 (BUC to OMT)
Part No. Nomenclature QTY
03P1097 Bolt, Hex 8
FP/5195 Gasket, CPR137-Full 1
HW/1-32HEXNUT Nut, Hex 8
HW/10-FLT Washer, Flat 16
HW/10-SPLIT Washer, Split 8
HW/GKT-CPR137G Gasket, CPR137-Half 1
Part No. Nomenclature QTY
32P1037 O-Ring 3
32P1039 O-Ring 3
HW/6-32HEXNUT Nut, #6 4
HW/6-32X7/8SHSC Screw, Socket #6 4
HW/6-FLT Washer, Flat, #6 8
HW/6-SPLIT Washer, Split #6 4
HW/8-FLT Washer, Flat #8 8
HW/8-SPLIT Washer, Split #8 8
HW/M4X12SHSC Screw, Socket, M4X12 4
HW/M4X25SHSC Screw, Socket, M4X25 4
