LCS-4 L-Band Combiner Switch Revision 1
Remote Control Operation MN/LCS4.IOM
A-18
Parameter
Type
Command
(Instruction
Code and
qualifier) Arguments
for Cmd or
Response
to Query
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Response to
Command
(Target to
Controller) Query
(Instruction
code and
qualifier)
Response to query
(Target to Controller)
Concise
Alarm Status N/A 41 bytes,
numerical Query only.
Used to Query the Alarm status of the LCS-4 response
is comma delimited.
Example: CMS=abcdefghijklmnopqr’cr’’lf’
where: a thru t = 0 or 1, 0 = OK 1 = FT
a = Main 48V Power Supply A Alarm
b = 12V Power Supply B Alarm
c = 12V Power Supply Alarm
d = +5V Power Supply Alarm
e = -5V Power Supply Alarm
f = BUC A Voltage Alarm
g = BUC B Voltage Alarm
h = BUC A Current Alarm
i = BUC B Current Alarm
j = BUC Switch Alarm
k = LNB A Voltage Alarm
l = LNB B Current Alarm
m = LNB A Current Alarm
n = LNB B Current Alarm
o = LNB Switch Alarm
p = Fan Current Alarm
q = REF Lock Detect PLL Alarm
r = BUC Redundancy Switch Alarm
w = LNB Redundancy Switch Alarm
t = Summary Fault Status
N/A CAS? CAS=abcdefghijklmnopqr (see
description for details of
arguments)
