LCS-4 L-Band Combiner Switch Revision 1
Remote Control Operation MN/LCS4.IOM
A-14
Parameter
Type
Command
(Instruction
Code and
qualifier) Arguments
for Cmd or
Response
to Query
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Response to
Command
(Target to
Controller) Query
(Instruction
code and
qualifier)
Response to query
(Target to Controller)
Cold Start CLD= 1 byte,
value of 0,1 Command or Query.
CLD enables masking reference lock detect for 3
minutes. During this time, the BUC references will be
disabled during this time. Values are:
0=Normal Operation
1=Cold Start Enabled
Example: CLD=1
Parameter 21 of SGC Command. CLD= (message ok)
CLD? (received ok,
but invalid
arguments found)
CLD* (message ok,
but not permitted in
current mode) CLD? CLD=x
(same format as command
arguments)
Remote
Address
(Physical
Address) SPA= 4 bytes,
numerical
Command or Query.
Physical Address – between 0001 and 9999.
Resolution 0001
Example:SPA=0890 SPA= (message ok)
SPA? (received ok,
but invalid
arguments found)
SPA* (message ok,
but not permitted in
current mode) SPA? SPA=xxxx
(same format as command
arguments)
Clear All
Stored
Events CAE= None Command only.
Instructs the target to clear all Stored Events. This
command takes no arguments.
CAE=(message ok) N/A
N/A
Retrieve next
5 unread
Stored
Events N/A 145 bytes Query only.
LCS-4 returns the oldest 5 Stored Events, which have
not yet been read over the remote control. Reply
format: Sub-body{CR}Sub-body{CR} Sub-
body{CR}Sub-body{CR}Sub-body, where Sub-
body=
yyyyyyyyyy zz mmddyy hhmmss
Where:
yyyyyyyyyy = being the fault description
ZZ = being the alarm type
FT=Fault
OK=Clear
IF=Information
If there are no new events, the LCS-4 will reply with
LNE*
AFR= (message ok)
AFR? (received ok,
but invalid
arguments found) AFR?
AFR=x
(same format as command
arguments)
Retrieve
Number of
unread
Stored
Events N/A 2 bytes,
numerical
Query Only.
Returns the number of Stored Events, which remain
unread, in the form xx.
Example: reply: TNE=18 N/A TNE? TNE=xx
(same format as command
arguments)
