2

BMW047S

Attaching the Paper Feed Unit

10. Lift the front of the tray, and slide it carefully into the printer until it stops.

BMW048S

11. On the rear of the unit, attach two brackets using the remaining screws.

Tighten the screws firmly using a coin.

BMW049S

12. Plug in the power cable, and then turn on the printer.
13. Print the configuration page to confirm that the unit was attached correctly.

• To confirm whether the optional paper feed unit was correctly attached, print the configuration

page, and check “Attached Equipment” on the configuration page. If the unit was attached cor-
rectly, the following will be displayed:

29
