Replacing the transfer roller – Pitney Bowes DP50S Color Printer User Manual
Page 119

1. The transfer roller is installed as shown below.
BMW019S
6
2. Holding the green grips on both sides, pull up the transfer roller.
BMW020S
3. Holding the green grips, pull out the transfer roller from the printer.
BMW021S
Replacing the Transfer Roller
Replacing the Fusing Unit, Transfer Roller, and Dustproof Filter
117
