Fiber Inspection Probe 93
A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
SPECIFICATIONS a
Size (H x W x D) 47 mm x 42 mm x 162 mm (1 7 / 8 in x 1 5 / 8 in x 6 3 / 8 in) b
Weight 0.3 kg (0.66 lb)
Resolution 0.55 μm
Camera sensor Five-megapixel CMOS
Visual detection capability <1 μm
Field of view
304 μm x 304 μm (high mag)
608 μm x 608 μm (mid mag)
912 μm x 912 μm (low mag)
Light source Blue LED
Lighting technique Coaxial
Capture button Available on all models
Magnification button Available on all models
Digital magnification Three levels
Connector USB 2
GENERAL SPECIFICATIONS
Temperature operating
storage –10 o C to 50 o C
–40 o C to 70 o C
Relative humidity 0 % to 95 % non-condensing
ACCESSORIES
Standard Optional
Video inspection probe (FIP-410B/420B) FIPT-BOX Plastic case divided into various compartments for tips
FC-SC tip for bulkhead GP-10-2175 Protective cap and cord assembly for FIP-400/400B
U25M universal patch cord tip for 2.5 mm ferrule GP-10-094 Soft pouch for FIP-400 and FIP-400B
Plastic case with various compartments for tips
Note
a. Typical.
b. Measurement excluding tip and including strain relief.
