Introducing the FIP-400B Fiber Inspection Probe and ConnectorMax2
2 FIP-400B
Available Models

The retaining nut holds tips securely in place, ensuring they are always
fastened in the correct position.

The status LED gives you information about the probe or the analysis
results.

The interchangeable adapter tips give you the possibility to use various
tips depending on the type of connector you are inspecting.
The probe comes equipped with a protective cap that fits over basic tips;
therefore, you do not need to remove the tip before putting the cap on.
Available Models
The features available for your probe are automatically detected when you
connect it to your unit. The table below shows which feature is available
for each model.
Note: The auto capture is not available in multifiber mode.
Note: When the internal temperature of the FIP-430B is too low, the probe
performs a warm-up that can last up to a minute.
Models Inspection Auto analysis Auto centering Auto focus Auto capture
FIP-410B X - - - -
FIP-420B X X X - -
FIP-430B X X X X X
