EXFO FIP-400B Fiber Inspection Probe and ConnectorMax2 - Manual (Page 83)

Inspecting Fiber Ends
Fiber Inspection Probe 77
Updating the Firmware and Software
3. If desired, modify the file name.
4. Tap OK to close the window.
You can now open the report with PDF reader from the location where the
file was saved. The HTML and MHTML reports are compatible with Internet
Explorer (IE 7 and latest), and the latest software release of FireFox and
Google Chrome.
Updating the Firmware and Software
The FIP-400B is designed to provide automatic software update
notifications and firmware updates whenever necessary. This allows you to
benefit from the updates of your unit each time you use it. The firmware
and software updates can be recommended or required.
To notify you, a message box appears each time a firmware or software
update is recommended.
When a firmware update is required, the application shows an error if you
choose not to update the FIP-400B. If a firmware update fails,
ConnectorMax2 performs a fault recovery procedure the next time the
FIP-400B is connected.
The FIP-400B becomes unavailable if a software update is required or
when a firmware update is in progress. The Live video button becomes
disabled in capture view and in video view, the capture button becomes
disabled as well.
C
AUTION
Do not disconnect the probe or turn off the unit when an update is
in progress.
