Inspecting Fiber Ends
Fiber Inspection Probe
65
Analyzing Captures
An indicator is located at the left of the available features. The color of this
indicator shows the status of the feature:
Color
Meaning
Grey
The item is not selected
Green
The item is selected and the
conditions allow the analysis.
Black
The item is selected but the
conditions do not allow the
analysis.
The auto focus process was
aborted by the user.
Red
The application is in timeout state
because it is unable to complete the
auto focus process. There are three
ways to reapply the auto focus:
Clear the auto focus check box
and select it again
Press the FIP-400B magnification
button for 1 second
From Capture mode, return to
Live video mode
