Editing the power meter test configurations – EXFO FIP-400B Fiber Inspection Probe and ConnectorMax2 User Manual
Page 46
Setting up Your Fiber Inspection Probe and ConnectorMax2
40
FIP-400B
Editing the Power Meter Test Configurations
Editing the Power Meter Test Configurations
You can activate and set pass/fail threshold parameters for your power
meter measurements. You can set thresholds for absolute power and
insertion loss. You can set different pass/fail thresholds for each available
test wavelength, or apply the same thresholds to all wavelengths. Values
that are greater than the predefined thresholds are displayed in white on a
red background. Values that are pass are displayed in green.
To edit the power meter test configurations:
1. From the Main Menu, select Test Config.
