Led indicator – EXFO FIP-400B Fiber Inspection Probe and ConnectorMax2 User Manual
Page 10
Introducing the FIP-400B Fiber Inspection Probe and ConnectorMax2
4
FIP-400B
LED Indicator
LED Indicator
The LED located on the probe gives you information about the probe or the
analysis results.
LED
Status
Flashing blue
Detection of the probe in progress
Analysis in progress
Waiting mode. The auto focus
process starts automatically when
you insert an optical fiber
connector (FIP-430B only)
Auto focus in progress (FIP-430B
only)
Probe is initializing
Flashing red
There is a major problem preventing
the probe from functioning properly
Blue
Probe detected and ready
On a computer, the USB port is in
suspend mode
Red
In Capture mode, current FIP result
status is Fail (FIP-420B and FIP-430B)
Green
In Capture mode, current FIP result
status is Pass (FIP-420B and FIP-430B)
