Opening and closing files – EXFO FIP-400B Fiber Inspection Probe and ConnectorMax2 User Manual
Page 69
Inspecting Fiber Ends
Fiber Inspection Probe
63
Opening and Closing Files
Opening and Closing Files
You can open captured files directly from the application to view them.
You can either open current .cmax2 files, .cmax files (not supported by
MAX-700B and MAX-FIP), or a legacy image file taken from a previous fiber
inspection.
The .cmax files, when saved with the ConnectorMax 2 application, are
compatible with ConnectorMax2 files. However, the .cmax2 files can be
opened with the ConnectorMax 2 application only.
Note: The accepted image formats for legacy files are .bmp, .jpg and .gif.
Note: Sample files are available on the platform.
To open a file:
1. From the main window, select File, and then Open.
2. Select the desired file, and then tap OK.
