Inspecting Fiber Ends
72
FIP-400B
Viewing Power Meter Results
Viewing Power Meter Results
You can view the power meter results stored in memory in a separate tab
(see Measuring Power or Insertion Loss on page 71). The global pass/fail
status also takes the power meter measurements into account.
To view power or insertion loss measurements:
Select the Power Meter tab. All your measurements are displayed in the
order they were performed.
Switches
between
current
measurement
and stored
measurement
