EXFO FIP-400B Fiber Inspection Probe and ConnectorMax2 User Manual
Page 62
Inspecting Fiber Ends
56
FIP-400B
Inspecting Fiber Ends (Multifiber)
12. Set the probe to High Magnification.
Note: The FIP-420B and FIP-430B probes show a low magnification connector
image in the overlay.
13. Center the appropriate connector in the array:
For multi-row tips, use the Y wheel to select the required fiber row.
For multi-row and single-row tips, use the X wheel to select the
required fiber.
Y wheel
X wheel
