Fiber Inspection Probe

83

6

Troubleshooting

Solving Common Problems

The table below presents common problems and their solutions.

Problem

Solution

I cannot analyze an


The image is not focused properly; use the focus knob on

the probe until the focus indicator displays the best value

available. Yellow indicates an acceptable range, and

green shows the preferred range.

Ensure that the probe is connected properly.

Ensure that the connector is aligned properly.

Ensure that the focus value is sufficient to perform the

analysis.

Ensure that you are using a high magnitude level.

I cannot see the fiber

on-screen

Connect the probe to the USB port of the unit.

Verify the probe connection status to see if

ConnectorMax2 is detecting the probe properly. If the

probe is connected properly, close ConnectorMax2 and

open it again.

If you are working with a FTB-500, ensure that the probe

is connected to the lower USB port located in front of the

unit.

The FIP internal

temperature is too high

Let the FIP cool down.

The FIP has encountered

a critical internal error

Contact EXFO for technical support.

Violation of EXFO

embedded software

copyright

Contact EXFO for technical support.

The auto centering does

not function properly

Clean the connector.

Adjust the image focus.
