Section 2: Advanced Topics
Echelon XML Tag Description
A few of the Echelon XML tags are described in Table 14 .
Table 14. XML Tag Description
Header Description
TIMESTAMP
CHAN_MEMB_TIMESTAMP
CHAN_RTNG_TIMESTAMP
SEND_LIST_TIMESTAMP These properties show the date and time of the last
updated. The ISO time string is read and converted
internally into a ULONG (4-byte unsigned integer) and
stored in memory in milliseconds counting from January 1,
1900. The default setting is the current date and time.
DEVICE_NAME Shows the name of the i.LON 600. This field is read only.
LOCAL_IP_ADDR Specifies the i .LON 600 router local IP address. It is in IPv4
dotted decimal with null terminated string. This field is read
only.
LOCAL_PORT Specifies the i .LON 600 router local IP port.
CONFIG_SERVER_IP_ADDR Specifies the Configuration Server IP address. It is in IPv4
dotted decimal with null terminated string.
CONFIG_SERVER_PORT Specifies the Configuration Server IP port.
TIME_SERVER1_IP_ADDR
TIME_SERVER2_IP_ADDR Specifies the primary or alternate SNTP time server IP
address. It is in IPv4 dotted decimal with null terminated
string.
TIME_SERVER1_PORT
TIME_SERVER2_PORT Specifies the primary or alternate SNTP time server IP
port.
BANDWIDTH_LIMIT_ENABLED Specifies whether or not bandwidth limit setting is
used/enabled.
Boolean value can be either 1 (true) or 0
(false) .
BANDWIDTH_LIMIT_VALUE Specifies the data limit, in kilobytes per second, that the
device will transmit on the IP channel to another device. If
selected, the default is 1000 KB per second.
AGGREGATION_ENABLED Specifies whether or not LonTalk packets aggregation is
used/enabled.
Boolean value can be either 1 (true) or 0
(false) .
AGGREGATION_VALUE Specifies the amount of time in milliseconds that the device
will wait to aggregate LonTalk packets before sending them
on the IP channel.
CHECK_STALE_PKTS_ENABLED Specifies whether or not LonTalk packets are checked
against their time limit specified in the channel timeout
value.
Boolean value can be either 1 (true) or 0 (false) .
CHANNEL_TIMEOUT Specifies the time limit in milliseconds for a single packet to
arrive at its destination. Set Timeout if you are sending
packets across a virtual private network or any
configuration that uses the Internet.
AUTHENTICATION_ENABLED Specifies whether or not MD5 authentication is used on a
LonWorks IP channel.
Boolean value can be either 1
(true) or 0 (false) .
AUTHENTICATION_SECRET Specifies the authentication key to set security on a
LONWORKS/IP channel. Default is zero.
REORDER_PKTS_ENABLED Specifies whether or not the device should wait for an out-
of-order packet. Boolean value can be either 1(true) or 0
(false).
72 Self Installing i.LON XML Configuration of EIA 852 Channel
