Section 1: Setting Up and Using the i.LON 600 L ON W ORKS /IP Server
7. Enter the TCP/IP parameters provided by your network administrator.
These settings are described in greater detail in the Configuring TCP/IP
Settings section below.
8. Reboot your i.LON 600 using the Reboot Web page for the parameters to
take effect.
9. Connect the i.LON 600 to your network.
10. Repeat steps 3-9 for each i.LON 600 you wish to install on your network.
Configuring TCP/IP Settings
Set the TCP/IP information for the i.LON 600 by following these steps:
1. From the Welcome screen, click TCP/IP in the menu. The TCP/IP Web
page opens.
Figure 15. TCP/IP Settings Web Page
2. Enter the following information:
Automatically Obtain
IP Address Set this option to have the i.LON 600 obtain its IP address, subnet mask, and default
gateway from the local network’s DHCP server. If this option is set, you have the
option of obtaining the Domain Suffix and/or DNS Server 1 automatically. If you
change this value, you must reboot the i.LON 600 for the change to take effect.
If the DHCP server cannot be contacted, the IP address will be set to
192.168.1.222
, the subnet mask will be set to
255.255.255.0
, and the default
gateway will be temporarily set to
192.168.1.222
. As soon as the DHCP server is
contacted, the i.LON 600 will reboot itself and receive a new IP address. This is not
recommended and requires additional configuration of the L
ON W ORKS /IP channel as
described in Chapter 7.
Manually Configure
IP Settings Set this option when specifying a static IP address, subnet mask, and gateway for the
i
.LON 600. This is the default (and recommended) setting. If you change this value,
you must reboot the i.LON 600 for the change to take effect.
24 Configuring the i.LON 600’s TCP/IP Settings
