C. Start-Up

CHECK EVAPORATOR FAN SPEED AND RECORD.

CHECK CONDENSER FAN SPEED AND RECORD.

AFTER AT LEAST 10 MINUTES RUNNING TIME, RECORD THE FOLLOWING MEASUREMENTS:

COMP A1

COMP A2

COMP B1

COMP B2

OIL PRESSURE

SUCTION PRESSURE

SUCTION LINE TEMP

DISCHARGE PRESSURE

DISCHARGE LINE TEMP

ENTERING CONDENSER AIR TEMP

LEAVING CONDENSER AIR TEMP

EVAP ENTERING AIR DB TEMP

EVAP ENTERING AIR WB TEMP

EVAP LEAVING AIR DB TEMP

EVAP LEAVING AIR WB TEMP

COMPRESSOR AMPS (LI)

COMPRESSOR AMPS (L2)

COMPRESSOR AMPS (L3)

CHECK THE COMPRESSOR OIL LEVEL SIGHT GLASSES; ARE THE SIGHT GLASSES SHOWING
OIL LEVEL AT

TO Vs FULL?

(Y/N)_______

NOTES:

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obiigations.

Book 11

PC 111

Catalog No 533-812

Printed in U S A

Form 38AH-14SI

CL-2

5-96

Replaces: 38AH-1331

Tab 3a
