Carrier 38AH044-134 - Manual (Page 4)

DUAL CKT SINGLE CKT
SUCTION
CONNECTiON(S)
2Ve" Dia [54 mm] 25/e" Dia [67 mm]
LIQUID
CONNECTION(S)
Va" Dia [22 mm] IVa" Dia [29 mm]
SUCTION C 2'-iVi6" [627mm] r-10^/w" [567mm]
LIQUID D 1'-10Vi6" [561mm] 1'-10yi6" [567mm]
SUCTION {Ckt A) V- 713 / 16 '' [503mm] 2'-%" [626mm]
SUCTION (Ckt B) 2'-%" [626mm] —
LIQUID (Ckt A) 2'-5%" [756mm] 2'-10%" [879mm]
LIQUID (Ckt B) 2'-10%" [879mm] —
RELIEF VALVES LOCATED ON
THE C0HPRE55OR5 ARE EQUIPPED
WITH A 3/8" 5AE FLARE FOR
FIELD CONNECTION
SCALE 1<6
6 1/8'-
CISS mi ]
OO
O O
ooooooOOOOO
O OOOO
TOP VIEW OF CONTROL BOX SHELF
WITH FIELD POWER SUPPLY CONNECTIONS. (SEE NOTE 4 ANO CHART I)
FIELD PONER SUPPLY
Chart 1, Field Power Supply Connections
UNIT VOLTAGE Hz DIAMETER — in. [mm] QTY
044 230 50 3% [92] 1
044, 054
208/230 60 3% [92] 1
346, 380/415 50 2V2 [63] 1
044, 054, 064 460,575,380 60 2Va [63] 1
208/230 60 2Va [63] 2
064
346, 380/415 50 3% [92] 1
LEGEND
C — Copper Fin Coils
MTG — Mounting
SAE — Society of Automotive Engineers
NOTES;
1 The approximate operating weight of the unit is:
-------------- --------------------------------- 1478 kg
1609 kg
1501 kg
1632 kg
1617 kg
[1813 kg
2 Unit must have clearances for airflow as fo lows:
Top — Do not restrict in any way
Ends — 5 ft [1524 mm]
Sides — 6 ft [1829 mm]
3 Mounting holes may be used to mount unit to concrete pad They are not recommended for mounting
unit to spring isolators If spring isolators are used, a perimeter support channel between the unit and
the isolators is recommended
4 One 35/s" (92 mm) diameter hole is recommended for single-entry power on size 064 (208/230-v) units
5. See Table 1 for rigging center of gravity (Dimensions X,Y) See Table 2A and 2B for A-D corner weights
6 Circled numerals in Top View refer to condenser fans by position
38AH-044— 3259 lb
38AH-044-C 3547 lb
38AH-054— 3309 lb
38AH-054-C 3597 lb
38AH-064— 3565 lb
38AH-064-C 3998 lb
Fig. 1 — Dimensions — Units 38AH044,054,064
