RX 400p
98-05044 4-56
R1
4.12.1 Beacon Signal Status Menu
This section of the menu tree provides access to information related to the status of
the beacon receiver primary channel. This submenu is detailed in Figure 4-12.
F? Auto/Auto AA$
SS 54?SNR?26? ^
MTP?100>?Q?25?
Unselected?Bx
ID?0001??H?01
Back@
Top?Menu@
Pressing the and keys allows you to scroll through the available options.
Pressing the button with any status information in focus will display the signal
tracking bar chart. Pressing the button with the Back@ or Top Menu@ item in
focus will take the menu system to the previous menu or the Main menu,
respectively.
F? Auto/Auto AA$
This menu displays the currently tuned frequency
(kHz) and modulation rate (bps) for the receiver’s
primary channel.
SS 54?SNR?26? ^
This menu item provides the signal strength(SS) and
signal to noise ratio (SNR).
There is a direct correlation of signal strength and
signal quality, however, high signal strength may not
translate into good reception if there is significant
noise present. The SNR value is more representative
of signal quality.
The SNR is the height of the signal above the noise
