Serial Interface Specifications
Item Specification
Serial Port Interface Level RS-232C
MAIN Connector DB9 Socket
AUX Connector DB9 Socket
MAIN Baud Rate 4800, 9600, or 19200 Baud
AUX Baud Rate 4800, 9600, or 19200 Baud
MAIN Output Protocol NMEA 0183
MAIN Input Protocol NMEA 0183
AUX Input Protocol RTCM SC-104 (Extrnl mode only)
Power Specifications
Item Specification
Input Voltage 9.2-48 VDC
Power Consumption with CDA-2B <6.5 W Nominal
Power Connector Circular 2-pin Locking Plug
Mechanical Characteristics
Item Specification
Enclosure Extruded aluminum with aluminum front
and back plates.
Length 203 mm (8.0”)
Width 125 mm (4.9”)
Height 53 mm (2.0”)
Weight 0.8 kg (1.76 lb.)
Antenna Connector TNC Socket
Environmental Specifications
Item Specification
Storage Temperature -40 °C to 85°C
Operating Temperature -32 °C to 74°C
Humidity 95% Non-Condensing
Table A-2 CDA-2B Specifications
Operational Specifications
Item Specification
Frequency Range, Beacon 283.5 - 325 kHz
LNA Gain, Beacon 34 dB
Frequency Range, L-band 1.525 - 1.575 GHz
LNA Gain, L-band 28 dB
