RX 400p
4-1 98-05044
R1
4 Operation
This chapter introduces the display and keypad features of the RX 400p, operating
modes, menu structure, and receiver default operating parameters.
4.1 Front Display and Keypad
The RX 400p features a 2-line by 16-character LCD and 3-button keypad. The
keypad is composed of an up arrow
, enter , and down arrow key. Figure 4-
1 shows the display and keypad of the RX 400p receiver.
Figure 4-1 RX 400p Display and Keypad
