RX 400p
98-05044 4-44
R1
4.10.2 WAAS Configure Menu
This menu allows you to change from the current WAAS mode to a different DGPS
mode. This portion of the menu system is detailed in Figure 4-10.
Diff@WAAS <
Pressing the and keys allows you to scroll through the differential options.
Pressing the button will change to the specified mode. If you do not wish to
change from the current differential mode, simply select WAAS and press the
button.
4.11 OmniSTAR Menu
This menu provides access to the signal status and configuration parameters of the
internal L-band receiver inside the RX 400p. Please note that the icon in the upper
right corner of the display will change to a vertical satellite symbol as shown in
Figure 4-5 when using corrections from the internal OmniSTAR receiver. This
portion of the menu system, including submenus, is detailed in Figure 4-11.
Signal?Status@?+
Configure@?????^
Back@
Top?Menu@
Pressing the and keys allows you to scroll through the available options.
Pressing the button with any item in focus will take the menu system to that
submenu. Pressing the button with the Back@ or Top Menu@ item in focus will
take the menu system to the previous menu or the Main menu, respectively.
