RX 400p

4-41 98-05044

BER?122:?? 0?

BER?134:?? 9?^
LN? 122: _54.0!
LN? 134: 178.0!
Elev122:? 9.8!
Elev134:? 5.0!
Az? 122: 114.0!
Az? 134: 252.6!
Back@
Top?Menu@

Pressing the

and

keys allows you to scroll through the available options.

Pressing the

button with any status information in focus will display the signal

tracking bar chart. Pressing the

button with the Back@ or Top Menu@ item in

focus will take the menu system to the previous menu or the Main menu,
respectively.

BER 122: 0

This menu item displays the bit error rate of PRN
122 AOR-W (Atlantic Ocean Region – West)
WAAS satellite signal. The bit error rate, as
discussed in Section 2.3.2 is an indication of the
signal acquisition quality. Good reception is
characterized by a rate of less than 20, a tolerable
rate is less than 150, and a no-lock condition is 500
or greater.

BER?134: 0 ^

This menu item displays the bit error rate of PRN
134 POR (Pacific Ocean Region) WAAS satellite
signal. The bit error rate, as discussed in Section
2.3.2 is an indication of the signal acquisition
quality. Good reception is characterized by a rate of
less than 20, a tolerable rate is less than 150, and a
no-lock condition is 500 or greater.
