Compaq 3200 User Manual
Page 176
G-3
Compaq Smart Array 3200 Controller Reference Guide
Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002
File Name: N-APPG.DOC Last Saved On: 12/8/98 11:15 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
The
Smart Array 3200 Controller has two Very High Density
Connector Interface (VHDCI) connectors on the mounting bracket for
Ports 1 and 2. Optional daughterboards (included in the Smart Array
3200 Controller option kit) provide one or two 68-pin Wide-Ultra SCSI-
3 connectors for internal drives. This provides SCSI ports externally,
internally, or both, without additional cabling to route internal channels
externally or vice versa. There is no Y cable required for the Smart
Array 3200 Controller.
