Compaq 3200 User Manual
Page 144
E-2 Understanding Drive Arrays
Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002
File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
A drive array can also consist of a single logical drive, as illustrated in Figure E-
2.
Daz-9-18.EPS
Physical
Drive 1
Physical
Drive 2
Physical
Drive 3
Logical
Drive 1
Drive Array
Figure E-2. Drive array with one logical drive
Figure E-3 illustrates a larger array with two logical drives across six physical
drives.
Daz-9-16.EPS
Physical Drives
Logical
Drive 1
Logical
Drive 2
Drive Array
Drive 1
Drive 2
Drive 3
Drive 4
Drive 5
Drive 6
Figure E-3. Drive array with six physical drives and two logical drives
