Appendix C
Specifications
This appendix provides physical, operating, and performance specifications for
the Smart Array 3200 Controller.
Table C-1
Smart Array 3200 Controller Specifications
Dimensions English International
Height 3.9 in. 9.9 cm
Length 13.75 in. 34.9 cm
Thickness (including Array Accelerator) 0.60 in. 1.5 cm
Total Weight (including Array Accelerator) N/A N/A
Temperature Range
Operating 50
°
to 95
°
F 10
°
to 35
°
C
Shipping -22
°
to 140
°
F -30
°
to 60
°
C
Relative Humidity (non condensing)
Operating 20% to 80% 20% to 80%
Non-operating 5% to 90% 5% to 90%
Power Required
+5V 2.6 amp
+12V 20 mA
-12V 20 mA
Heat Dissipated (maximum) 13.5 watts
SCSI Channels 2
Drives Supported (maximum, internal and
external)
15
Data Transfer Method 32-Bit Bus Master
SCSI Bus Transfer Rate (maximum) 40 MHz
PCI Bus Transfer Rate (maximum) 132 MB/sec
SCSI Bus Termination Required
SCSI Port Connectors (internal and external) 68-pin Wide-Ultra SCSI/Fast-Wide SCSI-2
(Wide SCSI)
