C-3
Compaq Smart Array 3200 Controller Reference Guide
Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002
File Name: J-APPC.DOC Last Saved On: 11/30/98 5:06 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
68-Pin Wide SCSI Connector Pin Assignments continued
Pin Signal Pin Signal
13 Ground 47 DB7*
14 Ground 48 DB Parity*
15 Ground 49 Ground
16 Ground 50 Ground
17 TERMPWR 51 TERMPWR
18 TERMPWR 52 TERMPWR
19 N/C 53 Int_Out*
20 Ground 54 Ground
21 Ground 55 ATN*
22 Ground 56 Ground
23 Ground 57 BSY*
24 Ground 58 ACK*
25 Ground 59 RESET*
26 Ground 60 MSG*
27 Ground 61 SEL*
28 Ground 62 C/D*
29 Ground 63 REQ*
30 Ground 64 I/O*
31 Ground 65 DB8*
32 Ground 66 DB9*
33 Ground 67 DB10*
34 Ground 68 DB11*
* - Active low signals
