Reznor MAPS - A,B,C Users Manual User Manual
R-410a refrigerant, Maps, Cabinet sizes a, b, and c

Form O-MAPSIII&IV Cabinets A/B/C, P/N 257004R8, Page 1
Form O-MAPSIII&IV Cabinets A/B/C (Version B.4)
Obsoletes O-MAPSIII Cabinets A/B/C (Version B.3)
Operation / Maintenance / Service
®
R-410A
Refrigerant
AG
EN
CY
PROCE
SS
ST
A
R
T-
U
P
PR
ODUCT
C
U
ST
O
M
ER
WAR
RA
NT
Y
CO
NVERGENT
QU
ALITY SYSTE
M
CQS
CQS
®
®
™
Applies to: Cabinet Sizes A, B, and C
of MAPS
®
III Models RCB, RDB,
RDCB, RDDB, RECB, REDB and
MAPS
®
IV Models RCC, RDC,
RDCC, RDDC, RECC, REDC
MAPS
®
Cabinet
Sizes A, B, and C
DANGER
This unit contains R-410A high pressure refrigerant. Hazards exist that could
result in personal injury or death. Installation, maintenance, and service should
only be performed by an HVAC technician qualified in R-410A refrigerant and
using proper tools and equipment. Due to much higher pressure of R-410A
refrigerant, DO NOT USE service equipment or tools designed for R22
refrigerant.
IMPORTANT: Do not release refrigerant to the atmosphere! If required service
procedures include the adding or removing of refrigerant, the service technician
must comply with all federal, state and local laws. The procedures discussed
in this manual should only be performed by a qualified HVAC technician.
