Form O-MAPSIII Cabinet D, P/N 222918R9, Page 34
Distributor
Blocks
Transformer
Grounding
Lug
Terminal
Blocks
Transformer
Pressure
Switch
Fuse Blocks
Typical Fuse Panel (located left
in the electric heat section)
Contactors
Bushing
SCR Controller(s)
(see illustration
above)
Terminal
Block
Contactors
Terminal
Blocks
Strain
Relief
Bushings
Access Panel attached to Electric
Element Assembly
(Slide out to remove element assembly.)
Sequencer(s)
FIGURE 25 - Location of Components on
Control Panels in the Electric Heat Section
Air Sensing Tube
Electric Heating Element
Cassette Assembly
(includes electric
heat elements)
Fuse Panel
(See
FIGURE
25.)
Electric Heat Control Panel
(See FIGURE 25.)
FIGURE 24 -
Electric Heat
Elements
5.0 Electric Heat Section Maintenance - Models RECB and REDB (cont'd)
Electric Heating Elements and Controls (cont'd)
