Form O-MAPSIII Cabinet D, P/N 222918R9, Page 14
3.6 Compressor
Maintenance
(cont'd)
3.0 Maintenance/
Service
Procedures
(cont'd)
monitor pressure drop across the drier. ( NOTE: Suction line filter drier must be
removed after 72 hours of operation.)
Step 12 includes the remaining procedures required for cleanup of a burnout.
Continue to Step 5.
□
Step 5. Braze on Suction and Discharge Lines
CAUTION;
Do not leave system open to the atmosphere any
longer than minimum required for installation. POE oil in the
compressors is extremely susceptible to moisture absorption.
Always keep ends of tubing sealed during installation. See Hazard
Levels, page 2.
Brazing materials must be able to withstand the high pressure of R-410A refrigerant.
A high temperature, silver phosphate type brazing with 5% or greater alloy is recom-
mended.
To prevent oxidation, purge tubing with 2-3 psig of regulated dry nitrogen while it is
being brazed. Open the service valve as needed to release the nitrogen. Do not allow
moisture to enter the system.
The installer is responsible for brazing and for complying with appropriate standard
refrigerant piping procedures.
CAUTION:
All brazing should be done using a 2 to 3 psig dry
nitrogen purge flowing through the pipe being brazed. See Hazard
Levels, pg 2.
CAUTION:
When brazing, protect all painted surfaces and
components from excessive heat. Wet wrap all valves but do not
allow moisture to enter the tubing. See Hazard Levels, page 2.
□
Step 6. Check System for Leaks
After installation is complete, pressurize the circuit to approximately 75 psig using
nitrogen and a few ounces of refrigerant. Check for leaks using soap bubbles or
other leak-detecting methods.
□
Step 7. Evacuate the Circuit
Evacuate one circuit at a time. Use a vacuum pump and micron gauge. Each
circuit must be evacuated to hold a 500 micron vacuum. Vacuum must be pulled
on both the discharge (high) and suction (low) side. Do the suction side first; and
the compressor discharge side second. To establish that a circuit is leak-free
and moisture-free, a standing vacuum test is recommended. Close off the valve
to the vacuum pump and observe the micron gauge. If the vacuum gauge does
not rise above 500 microns in one minute, the evacuation should be complete.
If the vacuum gauge does rise above 500 microns in one minute, evacuation
is incomplete or the circuit has a leak. Repeat as needed until evacuation is
complete. The evacuation process must be done on each circuit.
NOTE: Evacuation will not remove moisture from POE oil. Moisture must be
prevented from getting in the oil.
Continue and/or repeat Steps 6 and 7 until evacuation is complete.
CAUTION: Do not use the replacement compressor as an
evacuation assist and never apply voltage to a compressor while
it is in a vacuum. See Hazard Levels, page 2.
Moisture and air are harmful to the system because they increase the condensing
temperature, raise the discharge gas temperature, cause formation of acids, and
cause oil breakdown.
□
Step 4. Install New Filter Driers (cont'd)
