Chapter 3: Programming

Concord 4 Installation Manual

Edit sensors

Shortcut: 083

Default: None

This menu lets you view and, if desired, change the group and partition
assignment for each learned zone or sensor. For example, the display
shows:

S01 P1 G13 NC HW BACK DOOR

Where S01 is the zone/sensor number, P1 is partition 1, G13 is sensor
group 13, NC is normally closed, HW is hardwired, and BACK DOOR is
the programmed text name.

Other description codes include:

•

RF (wireless sensor)

•

TP (touchpad)

•

NO (normally open)

To edit sensors:

1. Press A

or B until the display shows

EDIT SENSORS

2. Press #

and the display shows the sensor or zone with the lowest

number.

3. Press A or B to scroll through all learned zones and sensors.

4. When the desired zone or sensor is displayed, press #

The display

shows

SENSOR PTN n

(current partition assignment).

5. Enter the desired partition number, then press #. The dis play shows
the new partition assignment.

6. Press A

or B

and the display shows

SENSOR GROUP nn

(current group assignment).

7. Enter the desired group number, then press #. The display shows the
new group assignment.
