4.3 Command Communication
56
Setting Reading Mode/Data Addition Functions
Function Command being sent
Respons
e
Description
Error
Code
Setting reading mode Change WP12n OK n= 0: Single label
1: Multi label 1
2: Multi label 2
3: Multi label 3
00, 02
05, 08
14
Confirm RP12 12n
Setting data send timing Change WP13n OK
N= 0: Sends data after reading
1: Sends after timing input turns off
00, 02
05, 07
14
Confirm RP13 13n
Setting repeat-read time in
multi label reading mode 1 or
2 Change WP41nnn OK
nnn=001 to 225
(by 100 ms step)
00, 02
05, 09
14 Confirm RP41 41nnn
Setting decoding match count Change WP43nnn OK
nnn=001 to 225
Confirm RP43 43nnn
Setting decoding match count
in additional information Change WP10n OK n= 0: No addition
1: Add
00, 02
05, 07
14
Confirm RP10 10n
Setting scans in additional
information Change WP11n OK n= 0: No addition
1: Add
Note:
Effective only when No. of decodings are added.
Confirm RP11 11n
Setting label orientation in
additional information Change WP14n OK n= 0: No addition
1: Add Confirm RP14 14n
Setting code type in additional
information Change WP17n OK n= 0: No addition
1: Add Confirm RP17 17n
