4-3
4
4 Specifications
LK-DN100 DeviceNet unit
*1 DeviceNet is a registered trademark of ODVA (Open DeviceNet Vendor Association).
Model LK-DN100
Name DeviceNet communication unit dedicated to LK-G5000 Series
Network
connection Communication
protocol DeviceNet* 1 compliant
Master unit ODVA-certified master unit
Transmission speed 500 kbps, 250 kbps, 125 kbps
Device type Generic
Transmission medium Dedicated 5 cables (2 signal cables, 2 power supply cables, 1
shielding cable)
Maximum trunk
line cable length Thick cable: 500 m (at transmission speed 125 kbps)
/ 250 m (at 250 kbps) / 125 m (at 500 kbps)
Thin cable: 100 m (at all transmission speed settings)
Communication type I/O communication (Poll)
Explicit message communication
Power supply 11 VDC to 25 VDC
Current consumption 10 mA max. (when network power supply 24 V is applied)
Environment
resistance Ambient temperature When one or less head expansion unit is connected: 0 to +50ºC
When two or more head expansion units are connected: 0 to +40ºC
Relative humidity 35 to 85% RH (no condensation)
Rated voltage 24 VDC±10% (supplied from controller)
Current consumption 200 mA max.
Weight Approx. 300 g
