1-5
1
1 Before Use
Connector
Terminal block
3
1
4
1.1
Disables control input, tolerance comparison and readout of
measurement values for OUT07 and higher.
4
2
1
2.0
Disables control input or tolerance comparison for any OUT,
and disables readout of measurement values for OUT3 and
higher.
5
2
2
2.0
Disables control input or tolerance comparison for OUT05
and on, and disables readout of measurement values for
OUT07 and higher.
6
2
3
2.0
Disables control input or tolerance comparison for OUT09
and on, and disables readout of measurement values for
OUT11 and higher.
7
2
4
2.0
Unused.
8
4
1
2.0
Disables control input or tolerance comparison for OUT03
and on, and disables readout of measurement values for
OUT07 and higher.
9
4
2
2.0
Disables control input and tolerance comparison for OUT11
and higher.
A
4
3
2.0
Unused.
B
4
4
-
Cannot be used due to stress placed on network.
C
8
1
2.0
Disables control input and tolerance comparison for OUT07
and higher.
D
8
2
2.0
Unused.
E
8
3
-
Cannot be used due to stress placed on network.
F
8
4
-
Cannot be used due to stress placed on network.
Terminal name
Function
FG
Functional ground terminal.
Ground to a ground resistance of 100 ohms or less.
SLD
Shield.
Connect shield wire from the dedicated CC-Link cable supporting Ver. 1.10
(OP-79426, OP-79427, etc.).
DG
Communication ground
DB
Communication signal Low
DA
Communication signal High
Switch setting
Multiple
Station
Version
Remark
