3 Connecting to DeviceNet

Changing the DeviceNet Communication
Unit Settings

This section explains the principle and operation of the DeviceNet controller (LK-DN100).

This manual describes only those functions and settings of the DeviceNet master device necessary for
communicating with the LK-DN100. Refer to the manual supplied with the master device for details on
functions and settings between the DeviceNet master device and a PLC.

Field network connection specifications

Slave attributes

 Notes on device profiles (attribute files for DeviceNet)

The table below shows the contents of the device profile.

General data

Vendor name

KEYENCE Corporation

Vendor ID

367

Device profile name

Generic

Profile No.

Product catalog number

3000

Product revision

1.1

Physical conformance data

Maximum network power
consumption

Connector type

Open-ended screw connector

Physical layer insulation support

Yes

Support LED

Module, Network

MAC ID setting

Node Address switch

Default MAC ID

Transmission baud rate setting

Data Rate switch

Support transmission rate

125 kbps, 250 kbps, 500 kbps

Communication data

Predefined Master/Slave

Group 2-only server

Connection Set support

UCMM and message group
support

N/A

Message splitting support for
sending

Compatible

NOTE
