2-18
2
2 Connecting to CC-Link
Write control buffer  X1000 CHG_PRG_ACQ
X1001 CHG_PRG_ERR
X1002 SYNC_TIM_ON_ACQ
X1003 SYNC_TIM_ON_ERR
X1004 SYNC_TIM_OFF_ACQ
X1005 SYNC_TIM_OFF_ERR
X1006 SYNC_ZERO_ON_ACQ
X1007 SYNC_ZERO_ON_ERR
..
.
..
.
X1048 OUT4_ZERO_ON_ACQ
X1049 OUT4_ZERO_ON_ERR
X104A OUT4_ZERO_OFF_ACQ
X104B OUT4_ZERO_OFF_ERR
X104C OUT4_ZERO_STATE
X104D OUT4_RESET_ACQ
X104E OUT4_RESET_ERR
X104F 
Write data buffer  D2000 CUR_PRG_NUM
D2001 SYSTEM_ERR_NO
D2002 COUNTER_LO
D2003 COUNTER_HI
D2004 OUT1_LO
D2005 OUT1_HI
..
.
..
.
D2010 OUT4_LO
D2011 OUT4_HI
LK-CC100 Signal
direction CC-Link master station
Device Signal name
