4-2
4
4 Specifications
Specifications
CC-Link unit LK-CC100
*1 CC-Link is a registered trademark of Mitsubishi Electric Corporation.
*2 The LK-G5000 Series supports the "extended cyclic transmission" and "station-to-station cable
length relaxation" of CC-Link Ver. 2.00.
Model LK-CC100
Name CC-Link communication unit dedicated to LK-G5000 Series
Network
connection Supported
CC-Link*
1 version
Ver. 1.10 (extended cyclic setting: single)
Ver. 2.00 (extended cyclic setting: double or more)*
2
Master unit CLPA-certified master unit (CC-Link Ver. 2.00/Ver. 1.10)
No. of occupied
stations 1 to 4
Communication
speed 156 kbps, 625 kbps, 2.5 Mbps, 5 Mbps, 10 Mbps
Connecting cable Dedicated CC-Link cable supporting Ver. 1.10
(shielded 3-core twisted-pair cable: OP-79426, OP-79427)
Connecting cable
total length 156 kbps:1200 m
625 kbps:900 m
2.5 Mbps:400 m
5 Mbps:160 m
10 Mbps:100 m
Station type Remote device station
Environment
resistance Ambient temperature When one or less head expansion unit is connected: 0 to +50ºC
When two or more head expansion units are connected: 0 to +40ºC
Relative humidity 35 to 85% RH (no condensation)
Rated voltage 24 VDC±10% (supplied from controller)
Current consumption 200 mA max.
Weight Approx. 300 g
