2-10
2
2 Connecting to CC-Link
• n: varies according to the station number of the LK-CC100.
• m (1 to 12): corresponds to the OUT number. m = 1 for OUT01, m = 2 for OUT02, etc.
Read
control
buffer  RY (n+16*m+3) OUTm_TIM_ON_REQ • Requests timing ON to OUTm at the
rising edge from OFF (0)  ON (1).
• Ends the request at the falling edge
from ON (1)  OFF (0).
RY (n+16*m+4)  System reserved
RY (n+16*m+5) OUTm_TIM_OFF_REQ • Requests timing OFF to OUTm at the
rising edge from OFF (0)  ON (1).
• Ends the request at the falling edge
from ON (1)  OFF (0).
RY (n+16*m+6)

System reserved
RY (n+16*m+7)  System reserved
RY (n+16*m+8) OUTm_ZERO_ON_REQ • Requests zero ON to OUTm at the
rising edge from OFF (0)  ON (1).
• Ends the request at the falling edge
from ON (1)  OFF (0).
RY (n+16*m+9)

System reserved
RY (n+16*m+10) OUTm_ZERO_OFF_REQ • Requests zero OFF to OUTm at the
rising edge from OFF (0)  ON (1).
• Ends the request at the falling edge
from ON (1)  OFF (0).
RY (n+16*m+11)  System reserved
RY (n+16*m+12)

System reserved
RY (n+16*m+13) OUTm_RESET_REQ • Requests reset to OUTm at the rising
edge from OFF (0)  ON (1).
• Ends the request at the falling edge
from ON (1)  OFF (0).
RY (n+16*m+14)  System reserved
RY (n+16*m+15)

System reserved
RY (n+16*13+0)  System reserved
..
.
 System reserved
LK-
CC100 Signal
direction CC-Link master station
RY
(Remote outputs) Signal name Explanation
