2 Connecting to CC-Link
 RY (Remote outputs)
RY (remote outputs) are control signals sent from the CC-Link master station to the LK-CC100.
LK-
CC100 Signal
direction CC-Link master station
RY
(Remote outputs) Signal name Explanation
Read
control
buffer  RY (n+0) CHG_PRG_REQ • Requests to change to the program
number stored in SET_PRG_NUM at
the rising edge from OFF (0)
 ON (1).
• Ends the request at the falling edge
from ON (1)  OFF (0).
RY (n+1)  System reserved
RY (n+2) SYNC_TIM_ON_REQ • Requests synchronized timing ON at
the rising edge from OFF (0)  ON (1).
• Ends the request at the falling edge
from ON (1)
 OFF (0).
RY (n+3)  System reserved
RY (n+4) SYNC_TIM_OFF_REQ • Requests synchronized timing OFF at
the rising edge from OFF (0)  ON (1).
• Ends the request at the falling edge
from ON (1)  OFF (0).
RY (n+5)  System reserved
RY (n+6) SYNC_ZERO_ON_REQ • Requests synchronized zero ON at the
rising edge from OFF (0)  ON (1).
• Ends the request at the falling edge
from ON (1)  OFF (0).
RY (n+7)  System reserved
RY (n+8) SYNC_ZERO_OFF_REQ • Requests synchronized zero OFF at
the rising edge from OFF (0)  ON (1).
• Ends the request at the falling edge
from ON (1)  OFF (0).
RY (n+9)  System reserved
RY (n+10) SYNC_RESET_REQ • Requests synchronized reset at the
rising edge from OFF (0)  ON (1).
• Ends the request at the falling edge
from ON (1)  OFF (0).
RY (n+11)  System reserved
RY (n+12)  System reserved
RY (n+13)  System reserved
RY (n+14)  System reserved
RY (n+15)  System reserved
RY (n+16*m+0)  System reserved
RY (n+16*m+1)  System reserved
RY (n+16*m+2)

System reserved
