KEYENCE LK-CC100/DN100 User Manual
Page 47
3-11
3
3 Connecting to DeviceNet
m (1 to 12): corresponds to the OUT number. m = 1 for OUT01, m = 2 for OUT02, etc.
Read
control
buffer
Bit (16*m+3)
OUTm_TIM_ON_REQ
• Requests timing ON to OUTm at the
rising edge from OFF (0)
ON (1).
• Ends the request at the falling edge from
ON (1)
OFF (0).
Bit (16*m+4)
System reserved
Bit (16*m+5)
OUTm_TIM_OFF_REQ
• Requests timing OFF to OUTm at the
rising edge from OFF (0)
ON (1).
• Ends the request at the falling edge from
ON (1)
OFF (0).
Bit (16*m+6)
System reserved
Bit (16*m+7)
System reserved
Bit (16*m+8)
OUTm_ZERO_ON_REQ
• Requests zero ON to OUTm at the rising
edge from OFF (0)
ON (1).
• Ends the request at the falling edge from
ON (1)
OFF (0).
Bit (16*m+9)
System reserved
Bit (16*m+10)
OUTm_ZERO_OFF_REQ • Requests zero OFF to OUTm at the rising
edge from OFF (0)
ON (1).
• Ends the request at the falling edge from
ON (1)
OFF (0).
Bit (16*m+11)
System reserved
Bit (16*m+12)
System reserved
Bit (16*m+13)
OUTm_RESET_REQ
• Requests reset to OUTm at the rising
edge from OFF (0)
ON (1).
• Ends the request at the falling edge from
ON (1)
OFF (0).
Bit (16*m+14)
System reserved
Bit (16*m+15)
System reserved
LK-
DN100
Signal
direction
DeviceNet master node
Offset
Signal name
Explanation
