3 Connecting to DeviceNet
• m (1 to 12): corresponds to the OUT number. m = 1 for OUT01, m = 2 for OUT02, etc.
• ***-ACQ and ***-ERR turn OFF (0) at the falling edge of ***-REQ from ON(1)
 OFF(0).
Write
control
buffer  Bit (14) READY_FLAG Turns ON (1) when the controller is not in
setting mode, communicating, running,
Able Tuning, or setting scaling from
measurement data.
Bit (15) SYSTEM_ERR_FLAG • Turns ON (1) when the controller or
expansion unit has a system error.
• When ON (1), all signals except
SYSTEM_ERR_NO become invalid.
Bit (16*m+0) OUTm_LO Turns ON (1) when the comparator output
for OUTm is LO.
Bit (16*m+1) OUTm_GO Turns ON (1) when the comparator output
for OUTm is GO.
Bit (16*m+2) OUTm_HI Turns ON (1) when the comparator output
for OUTm is HI.
Bit (16*m+3) OUTm_TIM_ON_ACQ Turns ON (1) when the timing ON process
for OUTm completes.
Bit (16*m+4) OUTm_TIM_ON_ERR Turns ON (1) when an error occurs during
the timing ON process for OUTm.
Bit (16*m+5) OUTm_TIM_OFF_ACQ Turns ON (1) when the timing OFF process
for OUTm completes.
Bit (16*m+6) OUTm_TIM_OFF_ERR Turns ON (1) when an error occurs during
the timing OFF process for OUTm.
Bit (16*m+7) OUTm_TIM_STATE Turns ON (1) when the timing for OUTm is
ON.
Bit (16*m+8) OUTm_ZERO_ON_ACQ Turns ON (1) when the zero ON process for
OUTm completes.
Bit (16*m+9) OUTm_ZERO_ON_ERR Turns ON (1) when an error occurs during
the zero ON process for OUTm.
Bit (16*m+10) OUTm_ZERO_OFF_ACQ Turns ON (1) when the zero OFF process
for OUTm completes.
Bit (16*m+11) OUTm_ZERO_OFF_ERR Turns ON (1) when an error occurs during
the zero OFF process for OUTm.
Bit (16*m+12) OUTm_ZERO_STATE Turns ON (1) when the zero for OUTm is
ON.
Bit (16*m+13) OUTm_RESET_ACQ Turns ON (1) when the reset process
completes for OUTm.
Bit (16*m+14) OUTm_RESET_ERR Turns ON (1) when an error occurs during
the reset process for OUTm.
Bit (16*m+15)

System reserved
LK-
DN100 Signal
direction DeviceNet master node
Offset Signal name Explanation
