3-2 Device Maps
3-12 - CC-Link Compatible Network Unit DL-CL1 User’s Manual (FD-S) -
Co
mm
u
ni
c
a
ting
w
ith t
he FD
-S
s
er
ie
s
3
Number [n] denotes the first relay number assigned to the DL-CL1.
*1 See "Reading an Output from a Sensor Amplifier" (page 3-17).
*2 See "Reading/Writing Settings or Status of a Sensor Amplifier" (page 3-21).
See "Issuing a Motion Command to a Sensor Amplifier" (page 3-20).
*3 See "Rewriting a Setting Value of a Sensor Amplifier" (page 3-21).
Remote Output RY (Master Station -> DL-CL1)
Operating
mode
Device no.
(HEX)
Name
Communication
method
Description Reading range
Monitor mode
2
Full mode
1
Full mode
2
RX[n] + AF
Temperature
lower limit
rewrite error
*3
Used when rewriting a setting value.
This is output if an error occurs with a sensor
amplifi er of any ID number during rewriting of
temperature lower limit setting value.
0:No Error
1:Error
RX[n] + B0
to B3
Integrated
fl ow quantity
setting-1 rewrite
complete ID 01
to ID 04
*3
Used when rewriting a setting value.
This is output when the integrated fl ow
quantity setting value 1 has been rewritten.
The output of each sensor amplifi er (ID 01 to
ID 04) corresponds to each RX.
0->1: Rewrite
complete
RX[n] + BF
Integrated
fl ow quantity
setting-1 rewrite
error
*3
Used when rewriting a setting value.
This is output if an error occurs with a sensor
amplifi er of any ID number during rewriting of
integrated fl ow quantity setting value 1.
0:No Error
1:Error
RX[n] + C0
to EF System
reserved
- Unusable
RX[n] + 7B
Remote ready -
This is output when the DL-CL1 is correctly
connected to the CC-Link system.
1: Proper communication is provided.Data
from the sensor amplifi er will be updated.
0: Proper communication is not provided.Data
from the sensor amplifi er will not be updated.
0: In preparation
1: Ready
RX[n] + DB
RX[n] + 17B
Operating
mode
Device
no. (HEX)
Name
Communication
method
Description Writing range
Monitor mode
2
Full mode
1
Full mode
2
RY[n] + 00
to 03
Integration reset
input
ID 01 to ID 04
*1
Receives integration reset input by assigning
each sensor amplifi er (ID 01 to ID 04) to each
RY.
0: OFF
1: ON
RY[n] + 0F System reserved - Unusable
RY[n] + 10
to 13
Flow rate hold
reset input
ID 01 to ID 04
*1
Receives fl ow rate hold reset input by
assigning each sensor amplifi er (ID 01 to ID
04) to each RY.
0: OFF
1: ON
RY[n] + 1F System reserved - Unusable
RY[n] + 20
to 23
Zero adjustment
input
ID 01 to ID 04
*1
Receives zero adjustment input by assigning
each sensor amplifi er (ID 01 to ID 04) to each
RY.
0: OFF
1: ON
RY[n] + 2F System reserved - Unusable
RY[n] + 30
to 33
Temperature
hold reset input
ID 01 to ID 04
*1
Receives temperature hold reset input by
assigning each sensor amplifi er (ID 01 to ID
04) to each RY.
0: OFF
1: ON
RY[n] + 3F System reserved - Unusable
RY[n] + 40
to 43
(Not used) - - -
RY[n] + 4F
to 50
System reserved - Unusable
RY[n] + 51
Request for
command
*2
Used when communicating under handshake
control program. This is input when requesting
command execution.
0->1: Request
execution
RY[n] + 52 System reserved - Unusable
